Surly - Bikes/frames: Surly Troll 145 F/set Xl Grn



Troll Frameset

Off-road touring can be a zesty enterprise, but it’s not without its perils. Bicycles are simple machines that are extremely efficient, but all simple machines carry along with them the chance of breaking down. This efficiency can get you in trouble if your bike decides to break down far away from the comforts of your parent’s basement. If you’re going to ride your bicycles where no one can see, you better take gear that’s up to the task. Troll is up to the task.

Our Troll was once a simple mountain bike frame with a few extras that made it nice for touring. The Troll has evolved into a frame that has been pushed deeper into the category of off-road touring. Its geometry is no longer suspension corrected, which gives it more room for a larger frame bag. We’ve also adorned this frame with our Gnot-Boost spacing, allowing you to use any mountain bike hub whether it be 135mm QR, 12 x 142mm thru-axle, or 12 x 148mm Boost hub. The chainstay yoke has been redesigned to be fully compatible with 26+ tyres and comes with the always-comfy Jones Loop bar. The dropouts still allow you to run disc brakes, fenders, a Rohloff hub, and racks simultaneously. It also comes with more braze-ons than you thought possible – there are four triple bottle mounts on the fork alone (don’t get excited, you can only run one Anything Cage per fork leg), as well as two more triple bottle mounts on the down tube.

Troll is a bike that has one purpose – and that purpose is to carry you as far away from society as possible. Man has known for eons the call of the indifferent forest. The inexorable march of time, and dumb shit like cell phones, have dulled our senses and made us afraid. Reclaim your animalistic tendencies atop Man’s greatest invention.

Frame Highlights

  • Rear Dropouts- Horizontal slotted with derailleur hanger, 145mm Gnot-Boost O.L.D. Features Rohloff torque arm slot and threaded eyelets for fenders, racks and Surly trailer mounts (10-12mm 135 adapters included)
  • Brake Compatibility- Disc and rim brake compatible. Disc mounts are 51mm IS Rim brake pivots are removable. Note: rear disc brake is limited to 160mm maximum rotor diameter and requires the use of Surly caliper adapter (included with frames and bikes)
  • Braze-ons/extras- Full-length Surly Trip Guide housing line guides for derailleurs and brakes; two sets of bottle cage mounts; removable post cantilever pivots; upper seatstay threaded barrels, 4 sets of triple bottle mounts, mid-and low-blade fully threaded through-blade fork eyelets; threaded holes for racks, fenders and trailer mounting nuts; Rohloff OEM2 axle plate mounting slot
  • Seatpost diameter- 27.2mm
  • Seatpost clamp- 30mm (Surly stainless included)
  • Headtube- 1-1/8" threadless
  • Front Derailleur Clamp- 6mm, top-pull or Shimano high direct mount (adaptor included)
  • Bottom bracket- 73mm shell width, threaded standard English (1.37" x 24t)
  • Chainring Clearance- 24/36/48t
  • Tyre Clearance- 26 x 3"
  • Fork- TIG-welded tapered & butted 4130 CroMoly, non-suspension corrected, tapered straight blade. Low- and mid-blade fully threaded through-blade rack eyelets; fender mount eyelets at dropout; 1-1/8" x 260mm threadless steer tube, 51mm disc mount (180mm max. rotor diameter), removable cantilever pivots, two sets of triple bottle mounts on each fork blade. Note: you can’t always mount bottles on the fork with every rack
  • Thru Axle- Surly 12x142/148 Rear Thru Axle (not included)

Note: Maroon colour is now discontinued and reduced accordingly

Geometry

geometry pdf


Free shipping on all website orders over 25 to UK mainland.

What Others Think...

email this page to a friend
  Product Description Colour  Size  Wt(g)  StockNo  Price
Per
  Dispatched in:

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Green  XS    FMSUTR40G  Web: £750.00    EACH  BUY

 add to wishlist

Special Order

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Black  XS    FMSUTR40K  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Maroon  XS    FMSUTR40R  Web: £600.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Green  Sm    FMSUTR41G  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Black  Sm    FMSUTR41K  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Maroon  Sm    FMSUTR41R  Web: £600.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Green  Md    FMSUTR42G  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Black  Md    FMSUTR42K  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Green  Lg    FMSUTR43G  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Black  Lg    FMSUTR43K  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Maroon  Lg    FMSUTR43R  Web: £600.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Green  XL    FMSUTR44G  Web: £750.00    EACH  BUY

 add to wishlist

In Stock

  Troll Frameset, 26w Off Road/Touring Butted 4130 Cr-Mo, inc Cr-Mo Fork. 145mm DO   Black  XL    FMSUTR44K  Web: £750.00    EACH  BUY

 add to wishlist

In Stock
